Features:
- The Minka-Aire AireControl RC600 (DL-4510) 6-speed handheld remote that came with Minka-Aire DC motor ceiling fans such as F617L Raptor and F745 Sabot.
- Install the A23 battery, matching the polarity marks, then turn the fan power off at the circuit breaker, and turn it back on. Within 60 seconds, press and hold the remote's STOP button for 10 seconds, and Do not press any other button first, and the down light blinks twice and the fan turns briefly when the code is learned.
- Six fan speeds (1 low to 6 high), STOP and light control with dimming.
- Learning frequency with 32 code combinations.
- Takes 1 A23 (12V) battery, not included.
Part/Model Number: RC600 / RC600
Power Information: 1 A23 Required, Not Included
FCC ID (if applicable): 2A767-DL4510
Frequency (if applicable): 315.0 MHz
Supplied with models (if applicable): F617L Raptor, F745 Sabot, F868L Sleek, F899L Ninety-Nine, F905L Artemis XL5, F1001 Dyno XL
Compatible with models (if applicable): RC600, DL-4510, 2A767-DL4510, F617L, F745, F868L, F899L, F905L, XL5, F1001
